South Crofty Mine headgear. Ore is hoisted by self-dumping skip to the ore bin, left of the headgear, waste rock is fed into trucks and conveyed to the dump (left in foreground). The pump, made in 1873, has an unequal beam (10 feet stroke in the cylinder and 9 feet in the shaft) and plungers are 20 feet diameter down to 1,150 feet below the surface. The shaft is 340 fms. deep. The headgear of Robinson's Shaft (335 fms. deep) is seen on the right. Photo P208023. Reproduced with the permission of the British Geological Survey ©NERC. All rights Reserved.
