Cabelway E - controls

Key:
1 - Hoisting drum clutch
2 - Traversing drum clutch
3 - Hoisting drum (foot) brake
4 - Traversing drum (foot) brake
5 - Forward - off -reverse motor switch
6 - Speed control (liquid resistance)
